Model 803B Surface and Volume Resistance Probe and Verification Fixtures

Overview:

The ETS Model 803B Surface and Volume Resistance/Resistivity Probe is designed to precisely measure surface or volume resistance on a wide variety of conductive, dissipative, and insulative materials. The electrodes are made from conductive silicon for excellent probe-to-test-surface contact and measurement accuracy. Measurements of 100 Ohms and greater can be made. The 803B comes complete with metal and acrylic test beds for both volume and surface resistance measurements.  The Model 803B complies with all of the common standards for measuring surface and volume resistance of conductive, static dissipative and insulative planar material. The probe is compatible with most resistance meters and works especially well with the recommended ETS Model 871 Wide Range Resistance Meter.

Features:
  • Industry leading probe for measuring surface and volume resistance
  • Concentric ring design with streamlined  x10 conversion to surface resistivity
  • Precision 5lb. weight meets industry specifications
  • Specially coated graphite silicone electrodes enable measurements of 100 ohms and greater
  • Ground and insulated test beds included
  • Optional verification fixtures are available to confirm measurement accuracy before use
STANDARDS:
  • ANSI/ESD STM11.11 – Surface Resistance Measurement of Static Dissipative Planar Materials
  • ANSI/ESD STM11.12  – Volume Resistance Measurements of Static Dissipative Planar Materials
  • IEC 61340-2-3 – Methods of test for determining the resistance and resistivity of solid materials used to avoid electrostatic charge accumulation
  • MIL-PRF-81705D – Barrier Materials, Flexible, Electrostatic Discharge Protective, Heat-Sealable
  • ASTM D257-14 – Standard Test Methods for DC Resistance or Conductance of Insulating Materials
  • JIS K6911 – Testing Methods for Thermosetting Plastics
Downloads
Product Details
Model 803B Resistance Probe and 809/819 Verification Fixtures Bundle - The ETS Model 803B Surface and Volume Resistance/Resistivity Probe is designed to precisely measure surface or volume resistance on a wide variety of conductive, dissipative, and insulative materials. The electrodes are made from conductive silicon for excellent probe-to-test-surface contact and measurement accuracy. Measurements of 100 Ohms and greater can be made. The 803B comes complete with metal and acrylic test beds for both volume and surface resistance measurements.  The Model 803B complies with all of the common standards for measuring surface and volume resistance of conductive, static dissipative and insulative planar material. The probe is compatible with most resistance meters and works especially well with the recommended ETS Model 871 Wide Range Resistance Meter.
Model 803B Surface and Volume Resistance Probe - The ETS Model 803B Surface and Volume Resistance/Resistivity Probe is designed to precisely measure surface or volume resistance on a wide variety of conductive, dissipative, and insulative materials. The electrodes are made from conductive silicon for excellent probe-to-test-surface contact and measurement accuracy. Measurements of 100 Ohms and greater can be made. The 803B comes complete with metal and acrylic test beds for both volume and surface resistance measurements.  The Model 803B complies with all of the common standards for measuring surface and volume resistance of conductive, static dissipative and insulative planar material. The probe is compatible with most resistance meters and works especially well with the recommended ETS Model 871 Wide Range Resistance Meter.
Model 809B – Surface Resistance Verification Fixture for 803B Probe - The Model 809B Surface Resistance Check Fixture is a two-sided check fixture designed in accordance with the requirements of ESD STM11.11. The fixture is used to verify the accuracy of the ETS Model 803B Probe prior to taking measurements on a sample material. The 500k ohm side is used to check the contact area and accuracy of the probe. The 1T ohm side is used to check system accuracy and to deterimine upper end electrification time.

$695.00Add to cart
Model 819 – Volume Resistance Verification Fixture for 803B Probe - The Model 819 Volume Resistance Calibration Check Fixture is used to verify the contact area of the center (sense) electrode when the Model 803B Probe is used to measure volume resistance.
